結構特點及性能介紹：

1、實現了自動化操作的需求，這是因?yàn)槠涞睦壍罏殍T鐵平野軌道，拉幅鏈條為離根鏈條，因此，達到了既省力，同時又節約資源的效果。不僅如此，采取這樣的鏈條和軌道形式，就大大減少了故障發生的概率，而且?guī)缀醪恍枰獫櫥Ｗo(hù)。

2、在使用拉幅定型機時，由于實際情況不同，那么當我們有需要時，可以根據實際條件來選擇不同的調節方式。例如烘箱頂部，可以調整幅絲桿，并且配備了獨立電機來驅動。因此，操作人員能夠單獨調節，或者是聯動調幅，具體使用哪種方式可根據需要選擇，非常方便。

3、可以借助PLC系統的幫助，對于拉幅定型機的工藝流程進行把控，同時還可以借助系統的作用，把這些有價值的信息存儲起來，方便以后進行查閱或修改。

優勢：

它是一款專門用于拉幅和熱定型的設備，并且能夠產生大量正負電荷，這些電荷可以中和物體上所帶的電荷。假如物體表面帶有負電荷，它就可以吸引氣流中的正電荷，反之則會吸引氣流中的負電荷來中和本身的正電荷。這樣，無論物體本身帶有哪種電荷，都可以被中和掉，就消除了靜電。可以將其稱為一種固定式消除靜電的專用設備，在安裝方面簡單易操作，性能穩定等特點。

主要作用:

通常是利用導熱油加熱定型機內的空氣，以達到對織物加溫的目的，在溫度到達一定時間后，會促進織物發生結構上的改變，從而定型為預定的目標。現在隨著技術不斷更新，已有拉幅定型機配置了監控系統。合成纖維具有較強的耐磨性能，其用于庖代金屬網的話，在使用壽命上增加了五倍之久，經濟效益大大增加，在工藝上，還可以織出更多不同的花紋。

Structure features and performance:

1, to achieve the automatic operation of the demand, which is because of its pull track for the cast iron Hirano track, pull the chain for the chain from the root, so it is not only saving, but also the effect of saving resources. Not only that, to take such a chain and track form, it greatly reduces the probability of failure, and almost no need to lubricate the protection.

2, in the use of pull type setting machine, because of the actual situation is different, so when we need, can choose according to the actual conditions of different regulation. For example, the top of the oven, you can adjust the width of the wire rod, and equipped with an independent motor to drive. Therefore, the operator can be individually adjusted, or linkage am, the specific use of which can be selected according to the need, very convenient.

3, with the help of the PLC system, the process of stretching machine to control, but also can make use of the system function, the stored valuable information, to facilitate subsequent access or modify.

Advantages:

It is a specially designed for drawing and heat setting equipment, and can produce a large number of positive and negative charges, which can neutralize the charge on the object. If the object has a negative charge on the surface, it can attract the positive charge in the air current, and vice versa will attract the negative charge in the air flow and the positive charge of itself. In this way, no matter what kind of charge, the object itself can be neutralized, it can eliminate the static electricity. It can be called a fixed type of electrostatic elimination of special equipment, in the installation of simple and easy to operate, stable performance and so on.

Main effect:

It is usually used to heat the air in the heat setting machine to achieve the purpose of heating the fabric. After the temperature reaches a certain time, it will promote the change of the fabric structure. Now with the technology is constantly updated, there are pull setting machine configuration monitoring system. Synthetic fiber has strong wear resistance, is used to replace the metal net, five fold increase in the use of long life, economic efficiency is greatly increased, in the process, but also can weave more different patterns.

主要技術參數

形式：熱風循環，單層臥式

車別：右手車（或左手車）

公稱寬度：3000

公稱速度：100m/min（速度范圍5－100m/min）

超喂率范圍：正超喂30，負超喂10

烘房溫度：100-230

熱源 ：載熱油，燃?xì)猓ǔ鞘忻簹猓烊粴猓簹猓夯蜌猓姡邏赫羝?/span>

持布形式：針鋏

落布形式：單擺式或擺、卷兩用落布或卷裝落布

探邊形式：高精度紅外探邊

導軌形式：無油潤滑的鋼板導軌或鑄鐵導軌

烘房節數：4-10節，每節長3m

烘房外形尺寸：（1344+n×3000）mm+（W+1816）mm×1737mm

機器外形尺寸：（16115+n×3000）mm+（W+2500）mm×2300mm

裝機功率：（55+n×15）KW（不包括電加熱功率）

工藝流程

平幅進布螺紋擴幅紅外對中軋車圓盤整緯下超喂機械整緯螺紋擴幅上超喂剝邊紅外探邊上針漿邊拉幅或熱定型冷風冷卻切邊、吸邊脫針擺式落布或小打卷

The main technical parameters

Form: hot air circulation, monolayer horizontal

Cars don't: right hand car (or the left hand car)

Nominal width (mm) :  3000

The nominal speed: 100 m/min (speed range 5-100 - m/min)

Super scope: feed rate is super fed 30, 10 negative overfeeding

Drying room temperature: 100-230

Heat source: heating oil, gas, city gas, natural gas, water gas, liquefied petroleum gas), electricity, high pressure steam

Prod-ucts hold cloth forms: needle

Off forms: single pendulum pendulum, take-up and cloth or cloth package

Delineation forms: high precision infrared delineation

Guide: oil-free lubrication plate conveyor or cast iron rail

Dryer section number: 4-10 section, each section 3 m long

Chamber shape size: (1344 + n + + 1816 (W) x 3000) mm mm x 1737 mm

Machine appearance size: (16115 + n + + 2500 (W) x 3000) mm mm x 2300 mm

Installed power: (55 + n x 15) KW (not including electric heating power)

The process flow

Open-width into cloth - thread enlarge picture - - rolling car - round consolidation in the infrared signature of the weft - overfeeding under - machine on the whole the weft - thread enlarge picture - hello - on the strip edge to infrared delineation, needle - plasma edge - stenter or heat styling to cold wind cooling, trimming, suction side to take off the needle, pendulum fall cloth or small volume
